Electric Roll Grooving Machine With Fold Trolly for Steel Pipe SCH10/SCH40 1"-12" (RG-5A)

KeyWords

Electric Roll Grooving Machine With Fold Trolly for Steel Pipe SCH10/SCH40 1"-12" (RG-5A)

12 inch roll groovers are designed to improve speed and efficiency for fire sprinkler and other industrial installations

Grooving Capacity: 1"-12"

Max Wall Thickness: 8mm

Power Supply: 1100W

Output Speed: 23RPM

Contact Now

Favorites

Detail Information

1"-12" light electric hydraulic pipe groove machine

Welding 1600mm hydraulic butt welding machine

The RG-5A electric hydraulic grooving machine is used to roll grooves on 1"-12" (DN33~DN300) SCH10/SCH20, 1"-8" (DN25~DN200) SCH10/SCH40 steel pipes and stainless steel.

Suitable for a variety of daily tasks involving fire protection pipes, this rolling groover is an integrated tool that includes a motor, hydraulic feed pump, foot switch and pipe rack.

The motor's built-in high-performance gear reduction system allows for a compact design and reduced noise levels.

The unique combination of a hydraulic feed pump and trough depth locking knob guarantees a quality trough and optimal efficiency.

scope

model	RG-5A
Applicable materials	Carbon steel, stainless steel
capacity	Suitable for 1"-8" steel pipe SCH10/SCH40
	Suitable for 1"-8" steel pipe SCH10/SCH40
	Suitable for 10"-12" steel pipe SCH10/SCH20
power supply	220V/110V
frequency	50Hz/60Hz
Maximum wall thickness	8mm
Motor Power	1100W
Output speed	23 rpm
Packaging gross weight	95kg
Package Size	754077cm

Ordering Information

catalog number	stage	strength	Voltage frequency
900050	single	1100W	220V, 50/60HZ
900051	single	1100W	110V, 50/60HZ

Standard Parts

Item Number	describe	net weight
911106	Drive roller 1"- 1 ½" (φ33~φ48)	1.15kg
911107	Driving roller 2"-3"(φ60~φ89)	1.15kg
911108	Drive roller 3 ½"~6" (φ101~φ168)	1.70kg
911019	Driving roller 8"-12" (φ219~φ325)	1.70kg
912041	Grooved roller 1"- 1 ½" (φ33~φ48)	0.90kg
912042	Grooved roller 2"-6"(φ60-φ168)	0.80kg
912043	Grooved roller 8"-12" (φ219~φ325)	0.70kg
998078	1"-12" pipe rack	6.90kg
998026	Foot switch	1.50kg

Product details picture

Pipe rack

Suitable for 1"-12" steel pipe

drive roller

Set 1"- 1 ½" (φ33~φ48)

A set of 2"-3"(φ60~φ89)

Set of 3 ½"-6" (φ101~φ168)

A set of 8"-12" (φ219~φ325)

_{Troughed roller}

A set of 1"- 1 ½" (φ33~φ48) ;

A set of 2"-6" (φ60~φ168);

8"-12" (φ219~φ325) set;

Foot switch

Foldable Trolly

Tolly with two wheels. easy to transport it
